• 4-Wheel Antilock Brake Sys
• 5G Modem
• Ford App
• Hill Start Assist
• Manual Locking Hubs
• Mono Beam Coil Spring Frt Suspension W/Stab Bar
• Rear View Camera
• Remote Keyless Entry
• Sync4 W/8" Screen

• 1Touch Dwn Dr/Pass Window
• 4.2" Cluster Display
• Air Cond, Manual Front
• Cloth Sun Visors
• Driver Seat-Manual Lumbar
• Outside Temp Display
• Particulate Air Filter
• Power Locks And Windows
• Steering:Tilt/Telescope, Cruise & Audio Controls

• Advancetrac With Rsc
• Airbags - Safety Canopy
• Belt-Minder Chime
• Driver/Passenger Air Bags
• Secure Pkg 1 Yr Included
• Securilock Anti-Theft Sys
• Sos Post-Crash Alert Sys
• Tire Pressure Monit Sys

XL F-250® (600A)

Fixed 10,000 lb. GVWR Package

Ford Security Package (1-year included with activation)

Pickup Box Delete

Snowplow Prep Package

Vehicle Integration System 2.0

Rear View Camera and Prep Kit

Ford Connectivity Package (1-year included)

XL Chrome Package

• A1 Z1 A S 600A 99A 44F TBM X3E 66D 153 18B 18J 425 43C 473 512 52B 592 66S 67B 86M 96V ZZ1 ZZ2 READING
• Spare Tire Wheel Carrier & Jack
• Oxford White
• VEHICLE INTEGRATION SYSTEM 2.0 -inc: programmable vehicle integration system Recommended for trucks that will utilize upfit aftermarket equipment
• Upfitter Switches: Located in overhead console
• Platform Running Boards
• PICKUP BOX DELETE -inc: rear view camera and prep kit Deletes tailgate tie down hooks rearview camera and 7/4 pin connector Incomplete vehicle package - requires further manufacture and certification by a final stage manufacturer In addition Ford urges manufacturers to follow the recommendations of the Ford incomplete vehicle manual and the Ford truck body builder's layout book (and applicable supplements) GVWR: 9 900 lbs Rear Bumper Delete Spare Tire Wheel Jack & Tire Carrier Delete
• FRONT LICENSE PLATE BRACKET -inc: Standard in states requiring 2 license plates and optional to all others
• DUAL AGM 68 AH BATTERY
• 410 AMP DUAL ALTERNATORS -inc: 250 Amp + 160 Amp
• 3.73 Electronic Locking Axle
• PRO POWER ONBOARD - 400W -inc: 1 in-dash mounted outlet
• Roof Clearance Lights
• XL CHROME PACKAGE -inc: 4 pickup box tie-down plates Halogen Fog Lamps Bright Chrome Hub Covers & Center Ornaments Chrome Rear Step Bumper Chrome Front Bumper
• TRANSMISSION: TORQSHIFT-G 10-SPEED AUTOMATIC -inc: SelectShift and selectable drive modes: normal eco slippery roads tow/haul and off-road (STD)
• TIRES: LT245/75RX17E BSW A/T -inc: Spare may not be the same as road tire
• SNOW PLOW PREP PACKAGE -inc: computer selected springs for snowplow application Note 1: Restrictions apply; see supplemental reference or body builders layout book for details Note 2: May result in deterioration of ride quality when vehicle is not equipped w/snowplow Note 3: Dual battery (86M) recommended w/6.8L or 7.3L gasoline engines; see body builders layout book for details Note 4: Tailgate removal kit w/protective caps can be provided free of charge by your authorized dealer Failure to install the protective caps results in damage to the electrical system not covered by the vehicle warranty See owner's manual for details
• TRAILER BRAKE CONTROLLER -inc: smart trailer tow connector
• Equipment Group 600A
• ENGINE: 6.8L 2V DEVCT NA PFI V8 GAS (STD)
• Four Wheel Drive
• Tow Hitch
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Brake Assist
• Steel Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Tow Hooks
• Heated Mirrors
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Power Door Locks
• Daytime Running Lights
• Automatic Headlights
• AM/FM Stereo
• MP3 Capability
• MP3 Capability
• Steering Wheel Audio Controls
• Bluetooth® Connection
• Telematics
• Auxiliary Audio Input
• Smart Device Integration
• Requires Subscription
• Bluetooth® Connection
• Pass-Through Rear Seat
• Rear Bench Seat
• Adjustable Steering Wheel
• Trip Computer
• Power Windows
• Keyless Entry
• Power Door Locks
• Cruise Control
• A/C
• Vinyl Seats
• Split Bench Seat
• Driver Adjustable Lumbar
• Passenger Vanity Mirror
• Smart Device Integration
• Requires Subscription
• Smart Device Integration
• WiFi Hotspot
• Power Windows
• Power Door Locks
• Trip Computer
• Security System
• Immobilizer
• Traction Control
• Stability Control
• Traction Control
• Front Side Air Bag
• Telematics
• Requires Subscription
• Tire Pressure Monitor
• Front Head Air Bag
• Rear Head Air Bag
• Driver Air Bag
• Passenger Air Bag
• Child Safety Locks

• Brakes
• Brake ABS System (Second Line): 4-Wheel
• Brake ABS System: 4-Wheel
• Brake Type: 4-Wheel Disc
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14.3
• Rear Brake Rotor Diam x Thickness (in): 14.3
• Cargo Area Dimensions
• Cargo Box (Area) Height (in): 21.1
• Cargo Box Length : Floor (in)
• Cargo Box Width : Floor (in)
• Cargo Box Width : Top, Rear (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume (ft³): 78.5
• Tailgate Width (in): 0
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 250 & 160
• Emissions
• Tons/yr of CO2 Emissions : 15K mi/year
• Exterior Dimensions
• Cab to Axle (in): 56.1
• Ground Clearance, Front (in): 8.5
• Ground Clearance, Rear (in): 8.5
• Ground to Top of Load Floor (in): 36.8
• Height, Overall (in): 81.3
• Length, Overall (in): 266.2
• Overhang, Front (in): 38.2
• Overhang, Rear w/o bumper (in): 47.6
• Wheelbase (in): 176
• Width, Max w/o mirrors (in): 80
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 48
• Interior Dimensions
• Front Head Room (in): 40.8
• Front Hip Room (in): 62.5
• Front Leg Room (in): 43.9
• Front Shoulder Room (in): 66.7
• Passenger Capacity: 5
• Second Head Room (in): 40.4
• Second Hip Room (in): 64.7
• Second Leg Room (in): 43.6
• Second Shoulder Room (in): 65.9
• Steering
• Steering Type: Re-Circulating Ball
• Turning Diameter - Curb to Curb (ft): 57.8
• Summary
• Body Code: T
• Body Style: SD Crew Cab
• Vehicle Name: Ford Super Duty F-250 SRW
• Suspension
• Axle Capacity - Front (lbs): 6000
• Axle Capacity - Rear (lbs): 7280
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Axle Type - Front: Non-Independent
• Axle Type - Rear: Rigid Axle
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 6340
• Suspension Type - Front: Other
• Suspension Type - Rear: Leaf
• Tires
• Front Tire Capacity (lbs): 6390
• Front Tire Order Code: TBM
• Front Tire Size: LT245/75SR17
• Rear Tire Capacity (lbs): 6390
• Rear Tire Order Code: TBM
• Rear Tire Size: LT245/75SR17
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Spare Tire Order Code: 512
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3400
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 13600
• Maximum Trailering Capacity (lbs): 13800
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1380
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 13800
• Weight Information
• Base Curb Weight (lbs): 6699
• Curb Weight - Front (lbs): 3981
• Curb Weight - Rear (lbs): 2718
• Gross Axle Wt Rating - Front (lbs): 4800
• Gross Axle Wt Rating - Rear (lbs): 6340
• Gross Combined Wt Rating (lbs): 21000
• Gross Vehicle Weight Rating Cap (lbs): 10000
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 17 X 7.5
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 17 X 7.5
